PCBA Capabilities
Our Full Range of PCB Assembly Capabilities Can Offer Responsive Flexibility to Customer’s PCBA requirements
Our PCB assembly capabilities range from single layer to 48layers PCBAs with basic thru-hole components soldering or different SMD packages in LGA, BGA, PQFN, and 01005 size. Our assembly capabilities include but are not limited to what are listed below. For more detailed PCB Assembly capabilities, please contact us directly.
PCB Materials
Process | Item | Capabilities | |
---|---|---|---|
SMT | PCB | Maximum PCB size | 1200*600mm |
Maximum PCB weight | 8kg | ||
PCB types | Rigid, flex ,rigid-flex PCB | ||
PCB thickness | 0.3mm–6mm | ||
Solder paste printing precision | ±25μm | ||
SPI | minimum inspection spacing of solder ball | 100μm | |
X-Y precision | 0.5μm | ||
Assembly | Dimensions of components | 0.3*0.15 mm²–200*125 mm² | |
Maximum height of components | 25.4mm | ||
Maximum weight of components | 100g | ||
BGA/CSP Minimum ball spacing, ball diameter | 0.30mm,0.15mm | ||
Assembly precision | ±22μm,±0.05° | ||
Maximum type of material components | 500 | ||
Reflow | Temperature precision | ±1℃ | |
Soldering protection | nitrogen protection | ||
Nitrogen control | ±200ppm | ||
AXI | Minimum components | 1005 | |
Minimum pin spacing | 0.4mm(QFP) | ||
Minimum solder thickness | 0.0127mm | ||
DIP | Dip | Plug-in technology | Automatic insert parts machine |
Wave soldering | Wave type | common wave、Selective wave | |
Conveyor path gradient | 4–7° | ||
common wave soldering precision | ±3℃ | ||
Selecting wave stability precision | ±0.06 mm | ||
Soldering protection | nitrogen protection | ||
Coating technology | Maximum size | 500*475*6mm³ | |
Maximum weight | 5kg | ||
Minimum nozzle diameter | 2mm | ||
Test | AOI | minimum package | 1005 |
Inspection content | wrong parts、missing parts、wrong polarity、misalignment、tombstone、 solder short、solder bridge、cold solder | ||
X-Ray | Magnification | Geometric magnification 2000;System magnification 12000 | |
Resolution | 1μm /nm | ||
Rotation angle&Tilt Angle | any ±45°+360° | ||
In-Circuit Test (ICT) | Number of test points | >4096 | |
Test content | Contact test、Open-short circuit test、CR test、No power mixed test、Boundary scan testing、Power on mixed test | ||
Functional test | Test content | Check the functionalityand performance of the PCBA | |
IC programming | Transfer the program into the internal storage space of the chip | ||
First Article Inspection (FAI ) | Checking the first PCBA sample soldering before production run | ||
Other reliability tests | Aging Test, Life Cycle Test,Vibration Test,Surge Test,Packaging Test,Button Life Test | ||
Turnkey | Assembly Types | Surface Mount Technology(SMT) Assembly,Through-Hole Assembly,Mixed Assembly,BGA Assembly | |
Box bulid Assembly | Custom Plastic & Metal Casings, Complete box build for a variety of applications | ||
Other services | Conformal Coating,Custom Packaging,Custom Label & barcode,Aftermarket Service andRepair | ||
